GW-JX-380 Multi-functional Intermittent rotary die-cutting machine
Function
GW-JX-380 multifunctional intermittent rotary die-cutting machine is developed to solve the problems of in-mold label inability to die-cut or low efficiency of using traditional equipment in label printing enterprises, and has obtained multiple patents. The machine integrates the full rotary die-cutting mode of in-mold label and the intermittent die-cutting mode of self-adhesive label. The two working modes can be interchanged at will. Small batches of in-mold labels can also be die-cut in intermittent mode. It is a good solution to the confusion of in-mold label projects in printing plants. In addition, lamination, striping or cutting can be selected.
Main Technical Parameter
|
Model |
GW-JX-380 |
|
Intermittent Max.Die Cutting Speed |
60 m/min |
|
Maximum Rotary Die Cutting Speed |
100 m/min |
|
Intermittent Maximum Die Cutting Length |
330 mm |
|
Self-Adhesive Die-Cutting Accuracy |
±0.15 mm |
|
In-Mold Marking Die-Cutting Accuracy |
±0.25 mm |
|
Die Cutting Positioning Method |
Color mark sensor |
|
Maximum Paper Feed Width |
380 mm |
|
Maximum Unwinding Diameter |
550 mm |
|
Maximum Rewinding Diameter |
550 mm |
|
Die-Cutting Magnetic Roller(Standard) |
120T/140T |
|
Total Power |
15 kw |
|
Size |
2900x1200x1500mm |
|
Machine Weight |
2800 KG |
|
Working Power Supply |
AV380 V50 HZ |
|
Air Pressure Requirements |
0.4~0.6 MPa |
|
Minimum Slitting Width |
16 mm |
Performance and features 1. Each unit has an independent servo drive system to ensure stable registration during printing. 2. The printing unit adopts an inking system with 23 ink rollers, 4 large-diameter plate rollers and an alcohol dampening system to ensure printing quality. 3. The pre-registration system records data into the sliding control station according to the printing length, and each unit will automatically adjust to its ready position. 4. Registration system: Each printing unit can remotely adjust registration, including linear, horizontal, and skew, without stopping the machine, saving time and reducing substrate waste. 5. The vacuum return flow control unwinding vacuum return cylinder should be able to prevent the back of the P/S label from being scratched during intermittent movement. 6. Fully automatic operating system without joystick, including pressure adjustment and ink roller cleaning. Roller imprinting, etc. 7. Easy to operate. It is equipped with a sliding touch screen control station that can be moved left and right to improve the operator's work efficiency. 8. The control system uses electronic components to ensure reliable operation. 9. The lubrication system has centralized automatic lubrication. 10. This equipment adopts offset printing machine technology, has reasonable structure, low noise and low energy consumption.
